13&25mm Syringe Filter for HPLC

The Sterile syringe filter produced by Aijiren is a single-use membrane-based filtration facility that is mostly used to remove particulate impurities from liquid and gas samples before analysis by HPLC, ion chromatography, gas chromatography, ICP, and dissolution testing methods. . Correctly filtering samples in chromatographic experiments can improve the quality and consistency of analysis results and reduce instrument downtime. The sterile syringe filter adopts high-temperature aseptic processing and vacuum packaging of liquid to ensure the cleanliness of the syringe filter. It is recommended to be used once.

Low protein binding rate: These filters have a low protein binding rate. When the sample is less bound, its fluidity increases, and it also has better diffusion properties. Samples purified with PES filters can produce better results by tolerating slight changes in their density-related properties.

Compared with Nitrocellulose membrane (NC membrane), PVDF membrane has many advantages. PVDF membrane has high mechanical strength, is not easy to break or curl; it has the advantages of low background, wide solvent compatibility, and excellent coloring ability; in addition, PVDF membrane can be repeatedly tested after proper treatment.

With PES syringe filter membrane mechanically strong character, it can handle high-temperature liquids, with great flow rate (better than PTFE), and low protein binding. With these features, PES syringe filters offer superior performance for use with biological samples and media culture. Workable pH range ~3-14.
Nylon: Nylon membrane filters are hydrophilic, flexible, tear-resistant, and autoclavable. They are resistant to a range of organic solvents and suitable for use with high pH samples. Nylon binds proteins. Unsuitable for acidic solutions. pH range ~3-14.
MCE (Mixed Cellulose Ester) syringe filters are an ideal choice when biological samples are involved. Mixed Cellulose is a hydrophilic membrane offering both low protein binding coefficients and exceptional flow rates.

Syringe filter is a disposable device used in laboratory settings to filter small volumes of liquid samples. It is commonly utilized to remove particulate matter and microorganisms from solutions before analysis or to protect sensitive instruments from contamination.
Syringe filters consist of a plastic housing with a membrane filter at one end and a female luer lock or luer slip connection at the other end. The filter membrane is typically made of materials such as nylon, polyethersulfone (PES), polytetrafluoroethylene (PTFE), or cellulose acetate.

Designed to be compatible for the use on all common automated filtration systems, Standard syringe filters are color coded. Aijiren syringe filters are labeled for method validation and certification. All syringe filters are autoclavable (121 ¡ãC and 1.1 bar for 30 min).

Aijiren’s syringe filters and vials reduce HPLC sample preparation time and the use of consumables, and the track-etched membrane is also essential for extruding liposomes for encapsulation and targeted drugs.

Features of MCE: uniform pore size, thin texture, low flow resistance, high filtration speed, low absorption, all items are quality tests for filter efficacy and housing integrity. The housing is pressure tested and can withstand pressures up to 75 psig (5.0 bar). Some filters are individually packaged aseptic packaging, certified, RNase, DNase and DNA free, and non-pyrogenic.

In chromatographic experiments, the sample is placed on the chromatographic column for analysis after the sampler is injected. However, the inner core of the sampler and the chromatographic column is relatively thin. If there are large particles in the sample, it may cause the device to block , Need to use Syringe Filter for preliminary sample filtration treatment.

In addition to HPLC, syringe filters have a multitude of other applications. A syringe filter adds a few minutes and a minimal expense to your testing process, but you will see a big return on your investment. Small volume venting£¬HPLC sample preparation£¬Removal of protein precipitates£¬Routine QC analysis£¬Dissolution testing.

13 mm Syringe Filters: For sample volumes <10 mL range; Ideal choice for most applications; Holdup (dead) volume is <15 ul; Female inlet luer lock; Maximum operation pressure <15 bar; Bubble point: Hydrophilic 2-3 bar; Hydrophobic 1-1.2 bar.

Among the many medium types of Syringe Filters produced by Aijiren, Polypropylene Syringe Filter is a special one. Because Polypropylene is often used to make the shell of Syringe Filter, there are fewer types of membranes made of Polypropylene. Aijiren finally decided to use this material to produce Syringe Filter after studying the production materials of many different manufacturers and the usage of different customers.

In HPLC analysis, the particle size of the chromatographic column packing is small and easily blocked by contaminant particles. Therefore, samples and solvents must be pre-filtered to remove particulate contaminants and protect the instrument.

The syringe filters are designed for easy and efficient filtration of liquids and gases. They feature a syringe-like structure with an inlet and outlet, allowing for direct attachment to a syringe or other fluid delivery systems. The filters remove particulates, microorganisms, and unwanted substances, ensuring clean and clarified samples for analysis.

Membrane: ?ICP Certified PES (Polyethersulfone)??
Use with: ?Strong bases, alcohols, proteins, peptides
Don¡¯t use with: ?acids, ketones, esters, halogenated or aromatic hydrocarbons.
Sterilization: ?Syringe filters can be sterilized by autoclave at 125¡ã for 15 minutes.
Applications: ?Ion chromatography, tissue culture filtration, filtration of proteins and nucleic acids, high-temperature liquids.

Aijiren Syringe Filter is a comprehensive range of non-sterile disposable syringe filters for reliable sample pre-treatment. Reproducible membrane quality and automated manufacturing processes ensure particles are removed from all samples, extending the life of analytical columns and minimizing injection port and valve damage. The Aijiren syringe filter is available in 0.22um and 0.45um porosity, 4, 13, 25 and 30mm diameters.

Aijiren manufactures a Syringe Filter that comes in a number of different membranes, PTFE membranes are hydrophilic and inert and fit many different types of agents, the details below contain the chemicals compatible with the PTFE Syringe Filter. In addition, the article number and specific specifications of Aijiren PTFE have been clearly described. If you have any needs, please leave a comment below for inquiry.

The Lab Use Syringe Filter MCE is a versatile filtration tool designed for laboratory applications. Constructed with high-quality mixed cellulose ester (MCE) material, these syringe filters offer excellent chemical compatibility and durability. They effectively remove particulates, microorganisms, and impurities from liquid samples, ensuring enhanced sample purity for accurate analysis.

syringe filter is a small, disposable filter device that is commonly used in laboratory settings for the filtration of liquids. It is designed to be attached to a syringe, allowing the liquid to be passed through the filter membrane under pressure.
syringe filter is a small, disposable filter device that is commonly used in laboratory settings for the filtration of liquids. It is designed to be attached to a syringe, allowing the liquid to be passed through the filter membrane under pressure.

Aijiren syringe filter membrane is made of polyethersulfone (PES), hydrophilic (Hydrophilic), pore size is 0.22¿˜m, shell diameter is 13mm, effective membrane diameter is 11.7mm, and effective membrane area is 1.09cmº†.

PTFE Syringe Filters consist of a polytetrafluoroethylene (PTFE) membrane and a polypropylene overmolded housing. Available in 13 mm and 25 mm diameters and 0.22 μm and 0.45 μm pore sizes. PTFE is the membrane of choice for use with aggressive solvents, liquids, and gases that can attack other membranes.

PTFE is hydrophobic and needs to be pre-wetted before being used with aqueous solvents. Used for: corrosive solvents, strong acids, alcohols, alkalis, aromatic hydrocarbons. Not suitable for: water-based samples.

Cellulose acetate is a very low protein binding membrane that is ideal for aqueous based samples and biological samples. It is a lower protein binder than either polyethersulphone or PVDF membranes, but has a lower chemical resistance than regenerated cellulose (RC). CA is a strong membrane mechanically and hydrophilic.

Polyvinylidene difluoride (PVDF):?designed for high tensile strength, high solvent resistance, and low protein binding, making them suitable for biomedical filtration, sterilization filtration, and HPLC sample preparation. pH range ~1-14.

Aijiren disposable cellulose acetate(CA) syringe filter devices are designed to provide clear filterate of aqueous and organic solutionsfrom small volumes up to 100 mL.

Many different types of materials are used in syringe filters. A variety of materials, diameters, pore sizes, and in sterile and non-sterile options are on our list. These syringe filters offer outstanding microfiltration for applications in HPLC, water treatment, environmental, biotechnology, beverages, food, pharmaceuticals, and other fields related.

Due to the high hydrophobicity of the PVDF membrane, it needs to be immersed in ethanol, methanol or other suitable solutions for activation. This product is only for scientific research by professionals, and must not be used for clinical diagnosis or treatment, or used for food or medicine, and must not be stored in ordinary residences. For your safety and health, please wear lab coats and disposable gloves for operation.
