0.22 Red PTFE Syringe Filter

Hydrophilic PTFE syringe filters offer a choice for aqueous samples that are diluted with harsh chemicals. These filters can handle high-temperature liquids, excellent flow rates, low protein binding, and are compatible with most bases, acids and organic solvents.

Syringe filter is a small, disposable device used for filtration purposes in laboratories and other scientific settings. It consists of a plastic housing with a membrane filter at one end and a female luer lock or male luer slip connection at the other end, allowing it to be attached to a syringe.
The purpose of a syringe filter is to remove impurities, particulates, or unwanted substances from a liquid sample before it is injected or analyzed. The membrane filter within the syringe filter acts as a barrier, selectively allowing only certain particles or molecules to pass through while retaining larger particles.

Convenient and Easy to Use£ºPES Syringe filters can be sterilized by autoclave at 125¡ãC for 15 minutes£¬Enhanced Luer Lock inlet prevents leakage; outlet fitting is a standard size male Luer-slip fitting for ease of filtrate collection, Come in bulk packs of 100 and not individually wrapped

Aijiren’s PVDF membrane (imported packaging, 6.6¡Á8.5cm, 0.2¦Ìm) is a pre-cut polyvinylidene fluoride (PVDF) imprinting membrane with a size of 6.6¡Á8.5cm and a pore size of 0.2¦Ìm. It is most commonly used for the transfer of protein from gel to membrane in immunoblot (Western blot), and can also be used for adsorption analysis, amino acid analysis, N-terminal protein sequencing, dot and slot blot detection, Glycoprotein color development and lipopolysaccharide analysis, etc.

In HPLC analysis, the particle size of the chromatographic column packing is small and easily blocked by contaminant particles. Therefore, samples and solvents must be pre-filtered to remove particulate contaminants and protect the instrument.

Polyethersulfone (PES): Hydrophilic, stable in low pH, have low levels of extractables, and exhibit low protein binding, making them suitable for many aqueous and organic solvents. PES membranes allow higher liquid flow than PTFE. Temperature resistant. pH range ~3-14 (sometimes quoted as 1-14).

Due to the high hydrophobicity of the PVDF membrane, it needs to be soaked in an appropriate solution such as ethanol before use to achieve the purpose of activation and make the membrane easier to bind proteins. This product is compatible with many dyes, such as Ponceau-S red, Coomassie brilliantblue, Sypro ruby, Transillumination, Toluidine blue, CPTS, Colloidal gold, India inkAmido black. Among them, after dyeing with dyes such as Ponceau and CPTS, the dyes can be washed off and the film can be used for further analysis; while dyes such as Coomassie Brilliant Blue, India ink, and amide black are irreversible, the film cannot be used after dyeing. For further analysis.

Aijiren’s expert staff is available via live chat and email to help you decide on the best membrane filter for your needs. Email us, and our helpful customer representatives will respond promptly¡ªin just one business day or sooner. And if you still need help deciding on the right product, we¡¯ll ship you a sample to ensure you receive the best membrane filter for your needs.

With PES syringe filter membrane mechanically strong character, it can handle high-temperature liquids, with great flow rate (better than PTFE), and low protein binding. With these features, PES syringe filters offer superior performance for use with biological samples and media culture. Workable pH range ~3-14.
Nylon: Nylon membrane filters are hydrophilic, flexible, tear-resistant, and autoclavable. They are resistant to a range of organic solvents and suitable for use with high pH samples. Nylon binds proteins. Unsuitable for acidic solutions. pH range ~3-14.
MCE (Mixed Cellulose Ester) syringe filters are an ideal choice when biological samples are involved. Mixed Cellulose is a hydrophilic membrane offering both low protein binding coefficients and exceptional flow rates.

In chromatographic experiments, the sample is placed on the chromatographic column for analysis after the sampler is injected. However, the inner core of the sampler and the chromatographic column is relatively thin. If there are large particles in the sample, it may cause the device to block , Need to use Syringe Filter for preliminary sample filtration treatment.

PES syringe filter is hydrophilic in nature, and has low protein binding, high flow rate and excellent chemical stability. In addition, it also contributes to oxidation stability, high heat and low concentration of extractable elements.

Hydrophobic PTFE (Polytetrafluoroethylene) syringe filters are suitable for gaseous and organic solutions, with excellent performance for high corrosive samples. It is possible for an extended sampling range using hydrophobic PTFE filters for wider chemical resistance to aggressive substances and outstanding temperature stability. A PTFE syringe filter is an ideal choice for filtering and de-gassing chromatography solvents.

Syringe filter is a disposable filter unit designed to remove impurities from liquids or gases using a syringe as the fluid delivery system.
It consists of a plastic housing with an inlet and an outlet, and a filter membrane positioned between them.
The filter membrane is often made of materials such as polypropylene, polytetrafluoroethylene (PTFE), or nylon.
To use a syringe filter, the liquid or gas to be filtered is drawn into a syringe, and then the syringe is attached to the inlet of the syringe filter.

Syringe filtration is a crucial technique in laboratory settings, playing a vital role in sample preparation for various analytical methods.

Ideal for use with aqueous and organic solvents, Nylon Syringe Filters are an excellent choice for filtering high-performance liquid chromatography samples. Nylon syringe filters are durable, tear resistant and wet evenly.
PES (Polyethersulfone ) syringe filter is natural hydrophilic which makes is an ideal choice (highly recommended) for aqueous solutions and alcohols. It’s not necessary to treat the filter membrane surface with wetting agents.

Our Syringe Filters are high quality, well packaged and sold at a fair competitive price. They are available in most of the major membrane materials including Nylon, PTFE, PES, MCE, PVDF, CA, PP, and GF which are supplied in 13mm, 25mm formats in virgin polypropylene housings.

Instructions for use and precautions:
1. It must be used with disposable syringes and glass syringes. The interface is standard. Put the needle filter on the syringe first, then pour the liquid into the syringe, press the push rod down, and collect the filtered liquid.
2. Do not use a syringe smaller than 10cc, because the small-volume column may cause the pressure to exceed the upper limit and cause damage to the filter membrane.
3. Only for laboratory use, one-time use, non-renewable.
4. The filtrate at the beginning of the part should be discarded. The volume is about the dead volume of the filter. Taking 25mm as an example, discard the first 1mL filtrate; or pre-clean the filter with 1 to 2mL of solution.

Aijiren’s membrane materials are supplied by the best names in the industry and the ISO9000 certified manufacturing is carried out to the highest standards, in certified clean room conditions, using the latest manufacturing technology to ensure a high quality, consistent product. All the syringe filters are HPLC certified.

PES syringe filter has the characteristics of hydrophilicity, low protein binding, high flow rate and good chemical stability. In addition, it also contributes to oxidation stability, high heat and low concentration of extractable elements. Aijiren’s PES syringe filters are ideal for ion chromatography, tissue culture filtration, protein, nucleic acid and high temperature liquid filtration. It helps you get accurate results in sensitive analysis of ionic analytes.

Membrane separation technology is hailed as “one of the most promising high-tech developments in the middle of the 21st century”. Among them, microporous membrane separation is the most eye-catching application in the fields of biology, chemical analysis and pharmaceuticals. There is no need to change the membrane and clean the filter, save the complicated and time-consuming preparation work, and is widely used in the laboratory.

Membrane: HPLC Certified Nylon
Use with: Bases, Most HPLC solvents, Alcohols, Aromatic Hydrocarbons, THF.
Don¡¯t use with: Acids, Aggressive Halogenated hydrocarbons, protein samples (Nylon is a high binder)
Sterilization: Syringe filters can be sterilized by autoclave at 125¡ã for 15 minutes.
Applications: General Laboratory filtration, most HPLC samples

Aijiren Syringe Filter is a comprehensive range of non-sterile disposable syringe filters for reliable sample pre-treatment. Reproducible membrane quality and automated manufacturing processes ensure particles are removed from all samples, extending the life of analytical columns and minimizing injection port and valve damage. The Aijiren syringe filter is available in 0.22um and 0.45um porosity, 4, 13, 25 and 30mm diameters.

Disposable non-sterile syringe filter devices are designed to provide fast and efficient filtration, premium quality and economy. The membrane could be PTEF, PVDF, PES, Nylon, MES, PP, CA, and can be suitable for different situations.

Sterile filtration is used in many applications: serum-containing or non-serum-containing media that supports the growth of cell cultures, reagents or solutions containing sensitive components that will degrade during high temperature processing, and when there is no autoclave, filtration should be added to the sterile growth media supplement Liquid, filter samples to avoid microbial growth during storage, filter buffers, remove particulate matter and avoid microbial growth during storage, filter biological samples to be analyzed, avoid microbial contamination of expensive equipment, filter environmental samples to be analyzed, filter fermentation liquids, Further purification or analysis.

The hydrophobic PTFE membrane has extensive chemical compatibility and very low dissolution, and is currently the most chemically resistant membrane among all filter membranes. Aijiren’s innovative design allows the PTFE filter to achieve a perfect balance between the increase in effective filtration area and the decrease in sample retention volume. The filter can withstand higher operating pressures, effectively avoiding leakage.

The shell of PTFE Syringe Filter is made of polypropylene (PP) with excellent chemical stability. It is made of different colors, which is convenient for users to distinguish products of different materials and avoid confusion. The filter membrane adopts imported high-performance filter membrane with stable product quality and good reproducibility. It is an ideal choice for laboratory filtration of samples. The standard interface is convenient to connect to various syringes, and it can also be directly connected to the needle of the 7725 valve, and the sample can be injected directly after filtration.
